MIRTEK-32-KZ-W32
WALL
Three-phase multifunctional electric energy meter with plug-in communication modules, to be mounted in a metering and distribution board.
Can be used for CT and CT/VT connection.
Can be used for CT and CT/VT connection.
Communication interfaces
-
Optical port -
Wired interface RS-485 -
Ethernet connection -
Radio frequency interface 433 MHz or 2400 MHz -
Combined GSM/GPRS + NB-IoT
Main features
- Electricity metering on an accrual basis, in total and separately: regardless of the tariff schedule and according to the tariff schedule in effect at the beginning of the day/month
- Dual-SIM capability to provide a redundant communication channel
- Extended voltage measurement range 0.55 to 1.3 Urated
- E-seals on the enclosure and the terminal cover
- Transparent terminal cover
- Built-in load control relay, hardware lockable
- Built-in ionistor redundant power supply unit (optional)
- Availability of four discrete inputs and four discrete outputs (optional)
- Flexible setting of tariff schedule
- Capable of storing the readings at the beginning of the day (for 128 days), at the beginning of the month (for 36 months)
- Configurable load profile: besides 30 minutes, averaging interval can be set to 1, 2, 3, 4, 5, 6, 10, 12, 15, 20, 30, and 60 minutes
- Supported data transfer protocols: MIRTEK, DLMS, IEC 60870-5-101-2006 and IEC 60870-5-104-2006 (option)
- At least 500 event log entries
