MIRTEK-12-KZ-D1
DIN-RAIL
Smart single-phase multifunctional electricity meter, bi-directional, DIN-rail mounted.
Communication interfaces
-
Optical port -
Wired interface RS-485 -
GSM (GPRS/3G/4G/LTE standards)
+ combined with NB-IoT -
Radio frequency interface
433 MHz or 2400 MHz
Main features
- Electricity metering on an accrual basis, in total and separately: regardless of the tariff schedule and according to the tariff schedule in effect at the beginning of the day/month.
- Dual-SIM capability to provide a redundant communication channel.
- Extended voltage measurement range 0.55 to 1.3 Urated
- E-seals on the enclosure and the terminal cover.
- Built-in load control relay, hardware lockable.
- Flexible setting of the tariff schedule.
- Capable of storing the readings at the beginning of the day (for 128 days), at the beginning of the month (for 36 months).
- Configurable load profile: besides 30 minutes, averaging interval can be set to 1, 2, 3, 4, 5, 6, 10, 12, 15, 20, 30, and 60 minutes.
- Supported data transfer protocols: MIRTEK, DLMS.
- At least 500 event log entries.
